Right Angle 4-Slot Screw Down Blade Fuse Block
Right Angle 4-Slot Screw Down Blade Fuse Block
SKU:fuse-block-screw-RA-4slot
In stock
BUNDLE & SAVE
Right Angle 4-Slot Screw Down Blade Fuse Block
📝 4-Slot Positive Blade Fuse Block (1-In, 4-Out)
This 4-slot positive blade fuse block provides simple, reliable power distribution for campervans, caravans, RVs, 4WDs, boats and custom automotive electrical setups. Designed with a single positive input and four fused outputs, it delivers clean circuit organisation in a compact, waterproof-protected housing.
⭐ Essential Benefits
• 1-in, 4-out design – Distribute one power feed safely across four circuits.
• Compact footprint – Fits tight installs without taking up valuable space.
• Clear protective cover – Waterproof, dustproof and insulated for long service life.
• Secure terminal hardware – Includes stainless M5 input stud and M4 output bolts.
• Wide application range – Suitable for automotive, marine and off-grid builds.
⚙️ Functionality
The fuse block accepts a single positive supply through an M5 stainless stud, then distributes it to four fused outputs using robust M4 terminals. The clear clip-on cover shields the fuses from moisture and debris while allowing quick visual inspection and easy access for maintenance. Compatible with standard ATC/ATO automotive fuses.
🔌 Compatibility
• Suitable for 12v and 24v DC systems
• Compatible with ATC / ATO blade fuses
• Ideal for cars, 4WDs, campervans, caravans, RVs, trailers, boats & small circuits
🧰 Installation Difficulty
🟢 2/5 (Easy)
Surface-mount install with simple positive feed and four-circuit distribution.
🔍 Features
• 1 × M5 stainless main input stud
• 4 × M4 stainless fused output terminals
• Waterproof, dustproof clear cover
• Accepts standard ATC / ATO fuses
• Strong black ABS housing
• Compact size for small panel areas
📊 Specifications
| Specification | Value |
|---|---|
| Max Voltage | 32V DC |
| Circuits | 4 |
| Fuse Type | ATC / ATO |
| Approx Dimensions | 93mm × 44mm × 32mm (with cover) |
| Mount Hole Centres | 65mm |
| Input | M5 stainless threaded stud |
| Output Terminals | M4 stainless bolts |
| Housing Material | ABS body + clear protective cover |
| Terminals | Tin-plated copper |
📦 What’s Included
• 1 × 4-slot positive blade fuse block with cover
• 4 × Mounting screws
🙌 Why Choose This Product?
This compact 4-circuit fuse block is perfect for small builds or accessory installations where space is limited. With durable terminals, waterproof protection and a clean 1-in, 4-out layout, it provides safe and dependable distribution for any 12–24V setup.
🚀 Our Promise
Order today for same-day dispatch and enjoy a cleaner, safer and more organised electrical installation.
